C PLUS


C PLUS

  • Maximum four print heads in staggered way!
  • Extreme speed up to 234m2/h!
  • Durable 400W AC servo system!
  • More precise carriage belt system!
  • GnTek negative pressure recirculation system!
  • Smart energy-saving IR dryer!
  • Dismountable design for low transportation cost!

Model

C3204SG PLUS / C3204SG PLUS

Print Head

4 Starfire 1024 / 2 Starfire 1024

Ink

C.M.Y.K  solvent/eco-solvent

Ink supply system

GnTek Negative Pressure Recirculation System

Printing Width

Max. 3200mm

Media Type

Frontlit, Backlit, Vinyl, Banner......

Feeding system

Automatic media feeling and taking up system with air shaft

Drying system

Pre, mid, post and extended heater plus smart IR drier

Printing Speed

300x400dpi234m2/h    300x400dpi129m2/h

600x400dpi209m2/h    600x400dpi115m2/h

300x600dpi163m2/h    300x600dpi86m2/h

600x600dpi146m2/h    600x600dpi76m2/h

300x800dpi127m2/h    300x800dpi67m2/h

600x800dpi112m2/h    600x800dpi59m2/h

Data Interface

External: USB2.0; Internal: High-speed SCSI

Working Environment

Temp.23~29 C, Humidity:50%~80%

Software

PhotoPRINT+GZ control console

Power

50Hz/AC,220V±10% 13A(printer)+34A(IR drier)

Dimension

LxWxH(mm):4840x1200x1530/5140x1150x1150

G.W./N.W.

1150kgs/886kgs

Specifications are liable to change Without prior notice. The printing speeds are measured in 3.2 m width printing.

A wide range of applications solution!

With continuous ink recirculation and robust repairable construction, Dimatix Starfire 1024 print head delivers unparalleled saturation and smooth gradient.



Robust, durable and precise body!

Reinforced CNC aluminum beam and dual linear guides assure high speed, high resolution printing in a long run.

*Double linear guides than GZC.

GnTek negative pressure recirculation solution !

GZ dual negative pressure recirculation system with pressure balancing unit and pressure protection unit assures steady ink delivery and minimum maintenance.



Optimized feeding and taking up system!

Feeding system with strong media holders is suitable for both light and heavy media. Taking up system with air shaft&dancer bar enables precise and steady rewinding.



Smart IR drier!

One-piece IR drier for easy installation and smart synchronizing function could dry the printing efficiently and save the electricity.

*Double power than GZC

400W AC servo system!

400W AC servo system has high torque and low vibration, assuring more stablle and precise carriage movement.
